Electro Spinner
The Electro spinner, capable of operating at ambient temperatures up to 300°C, is designed to produce uniform, ultra-fine fibres and Nano-materials. It features an electroforming chamber that ensures consistent fibre formation under controlled electrical fields, maintaining optimal humidity and temperature. Ideal for industries such as medical devices, filtration, and tissue engineering, the Electro spinner offers exceptional precision, quality, and versatility.
- Equipment Name :Fibre Forming Chamber for ceramic fibre preparation.
- Drying Chamber :0.8 m diameter, 300 mm height with a glass window for monitoring.
- Construction :Heat-resistant SS 316 with air circulation for uniform drying.
- Dimensions :External size of 1.0 m diameter x 800 mm height.
- Temperature Range :Ambient to 300° C.
- Nozzle Sizes :Includes 0.2 mm and 0.3 mm nozzles.
- Liquid Inlet :Digitalized liquid feed system for precise control.
- Nozzle Capacity :50 ml cup with orifices for consistent delivery.
- Heating :Kanthal heating element with fiber insulation.
- Motor :0.5 HP for efficient operation.
- Spindle Speed :2000-12000 RPM at the nozzle.
- Air Blower :Integrated heater and air blower for optimal drying.
- View Port :Accessible view port on the top.
